TOPWORKER 450 (OVAL)

TOPWORKER 450 (OVAL)

The Topworker 450 is our oval professional top loading kiln made in Stoke-on-Trent factory (UK), with a capacity of 450 litres (16.1 cu/ft) this model of kiln is ideal for professional studios and schools and colleges working on a medium to large scale.

Firing Capacity: 450 litres (15.7 cu/ft)
Maximum Temperature: 1300°C (Cone 10)
Chamber Dimensions: 1060mm wide x 780mm deep x 690mm high
External Dimensions: 1300mm wide x 1270mm deep x 1140mm high
Weight: 450Kg
Power:18.8 kW
Supply Required Single Phase (Amps): N/A
Supply Required 3 Phase (Amps): 30A
Standard Controller: CERA-10

The Side walls are low thermal mass 23 Grade 76mm thick bubble insulation brick with a 25mm backup insulation giving 101mm of insulation.
Outer jacket is stainless steel with adjustable tensioning clamps to enable the kiln to always be kept ridged throughout its lifetime.
The kiln lid is also low thermal mass 23 Grade 76mm thick backed up with 12.5mm of high grade fibre board giving a lid thickness of 88.5mm.
The lid top has a powder coated steel cover plate.
Gas struts make opening the kiln effortless.
The lid hinge allows the lid to move freely reducing the risk cracking during the firing.
The kiln floor has 108mm of super-efficient Ultralite granular insulation normally found in industrial kilns.
Three support bricks are located in the base to enable a shelf/bat to be placed above the insulation.

2 year warranty (elements excluded)

The CERA-10 controller is the latest technology in controllers, it incorporates new software giving improved efficiency and ease of programming along with up-to-date safety and diagnostic features.
The controller has 10 programs, each with 16 segments, offering enormous flexibility. Ideally suited to glass and pottery applications along with many other scientific, industrial & heat treatment applications.

For a full list of the technical specifications for this kiln, please refer to the ‘Specifications – Top Loading Potterycrafts’ on the resources page of the Fired Up Kilns website.

New to kilns? Then make sure you read this helpful information.

Furniture kits for larger kilns are normally bespoke as individual needs vary, contact us to discuss your kiln furniture requirements.

Note: Kilns need at least 230 volts under load (when the contactor clicks on), ideally on a dedicated circuit matching your kilns Amp rating. Sharing the circuit with other devices may trip your breaker. We are always happy to advise you or your electrician
